Glossary term: Planetary Nebula

Description: A planetary nebula is a cloud of gas and dust, coming from the external layers of a dying star and expanding into the general interstellar medium. The gas, energized by ultraviolet light from the dying star, glows with an emission-line spectrum. Some planetary nebulae are approximately spherical, and may look like a planet in a small telescope but their nature is completely different. Other planetary nebulae are not spherical, due to the star's rotation, magnetic field, or binarity.

Related Terms:



See this term in other languages

Term and definition status: This term and its definition have been approved by a research astronomer and a teacher

The OAE Multilingual Glossary is a project of the IAU Office of Astronomy for Education (OAE) in collaboration with the IAU Office of Astronomy Outreach (OAO). The terms and definitions were chosen, written and reviewed by a collective effort from the OAE, the OAE Centers and Nodes, the OAE National Astronomy Education Coordinators (NAECs) and other volunteers. You can find a full list of credits here. All glossary terms and their definitions are released under a Creative Commons CC BY-4.0 license and should be credited to "IAU OAE".

Related Diagrams


The bright stars in Andromeda form a Y-shape. Pegasus to the lower right. In the center is M31, marked with a red ellipse.

Andromeda Constellation Map

Caption: The constellation Andromeda showing the bright stars and surrounding constellations. Andromeda is surrounded by (going clockwise from the top) Cassiopeia, Lacerta, Pegasus, Pisces, Aries, Triangulum and Perseus. The brightest star in Andromeda (Alpheratz) is in the lower part of the constellation. Together with three stars in Pegasus it forms the asterism known as the "Great Square of Pegasus". The next two bright stars in the constellation (Mirach and Almach) form a line extending north-east from Alpheratz. Andromeda is a northern constellation and is most visible in the evenings in the Northern Hemisphere autumn. It is visible from all of the Northern Hemisphere and most temperate regions of the Southern Hemisphere but is not visible from Antarctic and Subantarctic regions. The most famous object in Andromeda, the Andromeda Galaxy is marked here with a red ellipse and its Messier catalog number M31. The yellow circle on the left marks the position of the open cluster NGC 752 and the green circle on the right marks NGC 7662 (the blue snowball nebula), a planetary nebula. The y-axis of this diagram is in degrees of declination and with north as up and the x-axis is in hours of right ascension with east to the left. The sizes of the stars marked here relate to the star's apparent magnitude, a measure of its apparent brightness. The larger dots represent brighter stars. The Greek letters mark the brightest stars in the constellation. These are ranked by brightness with the brightest star being labeled alpha, the second brightest beta, etc., although this ordering is not always followed exactly. The dotted boundary lines mark the IAU's boundaries of the constellations and the solid green lines mark one of the common forms used to represent the figures of the constellations. Neither the constellation boundaries, nor the lines joining the stars appear on the sky.
Credit: Adapted by the IAU Office of Astronomy for Education from the original by IAU/Sky & Telescope

License: CC-BY-4.0 Creative Commons Attribution 4.0 International (CC BY 4.0) icons

Aquarius Constellation Map

Caption: The constellation Aquarius along with its bright stars and surrounding constellations. Aquarius is surrounded by (going clockwise from the top) Pegasus, Equuleus, Aquila, Capricornus, Piscis Austrinus, Sculptor, Cetus and Pisces. Aquarius lies on the ecliptic (shown here as a blue line), this is the path the Sun appears to take across the sky over the course of a year. The Sun is in Aquarius from mid February to mid March. The other planets of the Solar System can often be found in Aquarius. Aquarius spans the celestial equator and is thus visible at some time in the year from all of planet Earth. In the most arctic or antarctic regions of the world, some parts of the constellation may not be visible. Aquarius is most visible in the evenings in the northern hemisphere autumn and southern hemisphere spring. The yellow circles with plus symbols superimposed on them mark the globular clusters M2 and M72. The green circles superimposed on plus symbols mark the planetary nebulae NGC 7293 (the Helix Nebula) and NGC 7002 (the Saturn Nebula). M73 (marked with an x symbol) is a coincident grouping of stars previously erroneously classified as an open cluster. The y-axis of this diagram is in degrees of declination and with north as up and the x-axis is in hours of right ascension with east to the left. The sizes of the stars marked here relate to the star's apparent magnitude, a measure of its apparent brightness. The larger dots represent brighter stars. The Greek letters mark the brightest stars in the constellation. These are ranked by brightness with the brightest star being labeled alpha, the second brightest beta, etc., although this ordering is not always followed exactly. The dotted boundary lines mark the IAU's boundaries of the constellations and the solid green lines mark one of the common forms used to represent the figures of the constellations. Neither the constellation boundaries, nor the lines joining the stars appear on the sky.
Credit: Adapted by the IAU Office of Astronomy for Education from the original by IAU/Sky & Telescope

License: CC-BY-4.0 Creative Commons Attribution 4.0 International (CC BY 4.0) icons
